2004 Hoermann 156 GTA
‘Pure sportiveness’ is what Hoermann calls it’s latest ‘Italian stallion of the famous Milanese car manufacturers’. This expression is picked up by the designers and engineers of Hoermann, an Alfa-Tuner from Bavaria. As a subsidiary of Abt Sportsline, the team to be beaten in the DTM, Hoermann are currently working on Alfa Romeo tuning programs.
Alfa-Romeo 156 was seen as a revolution, destined to become a modern classic. With the advancement of the 156 to the 156 GTA, the Italian constructors were able to make connect the 156 to the golden years of Alfa-Romeo motor sport. In the field of aftermarket tuning, Hoermann is proud to announce a details of their extensive tuning package for the Alfa-Romeo 156 3.2 V6 24V GTA.
To give the GTA the correct sound, Hoermann offers a stainless steel exhaust system. The two oval exhaust pipes (148 x 75 mm), award the 156 GTA a distinctive note that is easily remembered and recognized.
The combination between the height adjustable suspension and the performance handling system, which allows a lowering of 20 to 60 mm, helps control the 156 in more dynamic driving situations. For worthy deceleration, a kit is supplied by Hoermann including a brake-set in combination with the flexible steel brake lines.
With the Hoermann LS and Hoermann PS, the company offers two kinds of rims. The LS in the size 8.5 x 18 inch as well as the PS size 8.5 x 19 both casted in two pieces.
Story by Hoermann Motorsport, edited by Supercars.net
In Detail
submitted by | Richard Owen |
engine | 60 Degree, All Alloy, V6 |
position | Front Tansverse |
valvetrain | DOHC, 4 Valves per Cyl |
fuel feed | Direct Injection |
displacement | 3179 cc / 194.0 in³ |
bore | 93 mm / 3.66 in |
stroke | 78 mm / 3.07 in |
compression | 10.5:1 |
power | 186.4 kw / 250 bhp @ 6200 rpm |
specific output | 78.64 bhp per litre |
bhp/weight | 177.3 bhp per tonne |
torque | 300 nm / 221.3 ft lbs @ 4800 rpm |
body / frame | Unit Steel |
driven wheels | FWD |
front tires | 225/45ZR17 |
rear tires | 225/45ZR17 |
front brakes | Brembro Vented Discs w/ABS, EBD, ASR, 4-Pot Calipers, Vacuum Ass |
f brake size | x 305 mm / x 12.0 in |
rear brakes | Brembro Vented Discs w/ABS, EBD, ASR, Vacuum Assist |
r brake size | x 276 mm / x 10.9 in |
front wheels | F 48.3 x 21.6 cm / 19 x 8.5 in |
rear wheels | R 48.3 x 21.6 cm / 19 x 8.5 in |
steering | Rack & Pinion w/Power Assist |
f suspension | Double Wishbones w/Doubel Trailing Arms, Anti-Roll Bar, Telescop |
r suspension | MacPherson Struts w, Transverse Levers, Offset Coil Springs, Ant |
curb weight | 1410 kg / 3109 lbs |
transmission | 6-Speed Manual or Paddle Shift Sequential |
gear ratios | 3.500:1, 2.235:1, 1.520:1, 1.156:1, 0.971:1, 0.816:1, :1 |
final drive | 3.733:1 |
top speed | ~249.4 kph / 155.0 mph |
0 – 60 mph | ~6.3 seconds |
