1946 Cisitalia 202
As a successful businessman and experienced amateur driver, Piero Dusio started Cisitalia, officially known as Consorzio Industriale Sportive Italia. The company employed a wealth of talent to develop limited production sports cars that were based around upgraded Fiat components. Cisitalia’s first product was the D46, a small single seater which used a space frame to support its Fiat 1090cc engine and Fiat 500 suspension.
After producing a several customer D46s, and achieving a debut victory in the Brezzi Cup in Turin, Cisitalia focused on building small passenger car based on the D46, including it’s Fiat components and space frame chassis. Called the 202, each cars was finished as a rolling chassis and bodied by various design houses. Pinin Farina was responsible for a definitive coupe which set the visual standard for all future sports car bodies having a low and flat hood.
Since the 202 never made large scale production and all the cars were handmade, the small talented group at Cisitalia, including Carlos Abarth, Dante Giacosa and Giavonni Savonuzzi, made several variants of the 202. Of the more important versions, the SMM Nuvolari Spider was built and named after a class victory at the 1947 Mille Miglia. It is easily identified by its large rear fins, twin windscreens and usual Italian blood red paint scheme.
Partly due to expensive construction of the mid-engine, four wheel drive formula one car designed by Ferry Porsche, Cisitalia went into receivership in 1949 and was sold in 1952. In total, around 200 cars were made which made a large impact on the later marques, including Abarth’s later range of cars.
See full 1946 Cisitalia 202 Image Gallery
In Detail
type | Series Production Car |
engineers | Giovanni Savonuzzi |
engine | Modified Fiat Inline-4 |
position | Front Longitudinal |
aspiration | Natural |
valvetrain | 2 Valves per Cyl |
fuel feed | 2 Weber 36DR4SP Carburetors |
displacement | 1089 cc / 66.5 in³ |
bore | 68 mm / 2.68 in |
stroke | 75 mm / 2.95 in |
power | 52.2 kw / 70 bhp @ 5500 rpm |
specific output | 64.28 bhp per litre |
bhp/weight | 92.11 bhp per tonne |
body / frame | Aluminum Body over Modified Fiat Frame |
driven wheels | RWD |
front brakes | Drums |
rear brakes | Drums |
steering | Worm & Roller |
f suspension | Fiat 1100 Wishbones w/Transverse Leaf Springs, Telescopic Dampers |
r suspension | Fiat 1100 Live Axle w/Transverse Leaf Springs |
curb weight | 760 kg / 1676 lbs |
wheelbase | 2400 mm / 94.5 in |
front track | 1258 mm / 49.5 in |
rear track | 1247 mm / 49.1 in |
transmission | 6-Speed Manual |
top speed | ~160.9 kph / 100.0 mph |
